Reaction-Bonded Silicon Carbide (LY101(SiSiC))

Reaction-Bonded Silicon Carbide (LY101(SiSiC)) is produced by mixing SiC powder with powdered carbon and a plasticizer, forming the mixture into the desired shape, burning off the plasticizer, and then infusing the fired object with free silicon and additive in a vacuum sintering furnace at 1500°C. Reaction sintered silicon carbide has the characteristics of good lubricity, small friction coefficient and wear resistance. It can be used to make bearings and sealing rings and is widely used in the fields of petroleum, chemical, automobile, ship, pump and valve.

Property Value
General
Chemical Formula  LY101(SiSiC)
Mechanical
Density  ≥3.03 g/cm³
Rockwell Hardness(HRA) 93.4
Modulus Of Elasticity  391GPa
Flexural Strength (3Points) 374MPa
Compressive Strength  2560MPa
Poissons Ratio  0.14 - 0.19
Fracture Toughness  3.95 MPa m½
Electrical
Volume Resistivity  1 x 104  ohm-cm
Thermal
Coefficient Of Thermal Expansion  4.3 x 10-6 /°C
Thermal Conductivity  160 W/mK
Specific Heat  0.67 cal/g °C
Shock Resistance  400 °C Diff.
Maximum Working Temperature  1350 °C
All properties are at room temperature unless otherwise noted.
