Microporous Pressureless Sintered Silicon Carbide Plus Graphite LY204 (Microporous SSiC+G)
Microporous Pressureless Sintered Silicon Carbide Plus Graphite LY204 (Microporous SSiC+G) contains both fine graphite particles and spherical micropores for storing fluid media. It combines all the excellent properties of pressureless sintering SIC and pressureless sintering SSIC+G and microporous SSiC. It maximizes the dry friction resistance and thermal shock resistance of the material, which can meet the most severe working conditions and is especially suitable for making high-performance canned pump components and magnetic pump components.
| Property | Value |
| General | |
| Chemical Formula | LY204(Microporous SSIC+G) |
| Mechanical | |
| Density | 2.08-2.84 g/cm³ |
| Rockwell Hardness（HRA） | 80 |
| Modulus Of Elasticity | 336GPa |
| Flexural Strength (3Points) | 232MPa |
| Compressive Strength | - |
| Fracture Toughness | - |
| Electrical |
|
| Volume Resistivity | - |
| Thermal | |
| Coefficient Of Thermal Expansion | - |
| Thermal Conductivity | 135W/mK |
| Specific Heat | - |
| Shock Resistance | - |
| Maximum Working Temperature | - |
| All properties are at room temperature unless otherwise noted. | |
